| Specifications |
| Camera |
| Image Sensor |
1/2.9" Progressive Scan CMOS |
| Min. Illumination |
Color: 0.01 8 Lux @(F 1.6, AG CON) |
| Shutter Speed |
1/3 s to 1/100,000 s |
| Slow Shutter |
Support |
| Lens |
2.8-12mm @F1.6, Motorized Lens, Angle of view：88° to 27° |
| Lens Mount |
Φ14 |
| Day & Night |
IR cut filter |
| DNR |
3D DNR |
| Wide Dynamic Range |
120dB |
| 3 Axis Adjustment |
Pan:0° - 355°, Tilt: 0° - 90°, Rotation: 0° - 355° |
| Compression Standard |
| Video Compression |
Main stream: H.265+/H.265/H.264 Zip+/H.264
Sub stream: H.265+/H.265/H.264 Zip+/H.264/MJPEG
Third stream: H.265+/H.265/H.264 Zip+/H.264
|
| H.264/H.264+ |
Main Profile / High Profile |
| H.265/H.265+ |
Main Profile / Main Stream Support |
| Video Bit Rate |
32 Kbps to 16 Mbps |
| Audio Compression |
G722.1/G711ulaw/G711alaw/G726/MP2L2 |
| Audio Bit Rate |
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2) |
| Image |
| Max. Resolution |
3072 × 2048 |
| Frame Rate |
50Hz: 20 fps (2944× 1656), 25 fps (2560 × 1440, 1920 × 1080, 1280 ×720)
60Hz: 20 fps (2944×1656), 30 fps (2560 × 1440, 1920 × 1080, 1280 ×720)
|
| Sub Stream |
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
|
| Third Stream |
50Hz: 25fps (1280 ×720, 640 × 360, 352 × 288)
60Hz: 30fps (1280 ×720, 640 × 360, 352 × 240)
|
| Image Setting |
Rotate mode, saturation, brightness, contrast, sharpness adjustable by client software or web browser
|
| Network |
| Network Storage |
Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR |
| Alarm Trigger |
Motion detection, video tampering, network disconnected, IP address conflict, illegal login,
HDD full, HDD error, Alarm input, Alarm output
|
| Protocols |
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| General |
One-key reset, anti-flicker, three streams, heartbeat, password protection, privacy mask, watermark,
IP address filter
|
| Standard |
ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI |
| Interface |
| Communication Interface |
1 RJ45 10M/100M self-adaptive Ethernet port |
| Reset |
Yes |
| General |
Working Temperature
/Humidity |
-22 °F ~ 140°F (-30 °C ~ 60 °C)
Humidity 95% or less (non-condensing) |
| Power Supply |
DC12V ± 25%, PoE (802.3af) |
| IR Range |
Up to 165ft (50m) |
| Weather Proof Ratings |
IP67 |
| Impact Protection |
IK10 |
| Dimensions |
Φ 5 .7” × 13.1”(Φ 144.13 × 332.73 mm) |
| Weight |
4.2 lbs (1893 g) |
|
