| Specifications |
| Camera |
| Image Sensor |
1/2.5" Progressive Scan CMOS |
| Min. Illumination |
Color: 0.01 Lux @ (F1.2, AGC ON), 0.028 Lux @ (F2.0, AGC ON), 0 Lux with IR |
| Shutter Speed |
1/3 s to 1/10,000 s |
| Lens |
2.8mm, horizontal FOV: 102°, vertical FOV: 53°, diagonal FOV: 124° |
| Lens Mount |
M12 |
| Day & Night |
IR cut filter |
| DNR |
3D DNR |
| Wide Dynamic Range |
120dB |
| Angle Adjustment |
Pan:0° ~ 355°, Tilt: 0° ~ 75°, Rotation: 0° ~ 355° |
| Compression Standard |
| Video Compression |
Main stream: H.265/H.264
Sub stream: H.26 5/H.264/MJPEG
Third stream: H.265/H.264
|
| H.264 Type |
Main / High Profile |
| H.265 Type |
Main Profile |
| Video Bit Rate |
32 Kbps ~ 16 Mbps |
| Dual Stream |
Support |
| Image |
| Max. Resolution |
3840 × 2160 |
| Main Stream |
50Hz: 20 fps (3840 × 2160), 25 fps (2560 × 1920, 2560 × 1440, 1920 × 1080, 1280 × 720) 60Hz: 20 fps (3840 × 2160), 30 fps (2560 × 1920, 2560 × 1440, 1920 × 1080, 1280 × 720) |
| Sub Stream |
50Hz: 25fps (640 × 360, 352 × 288)60Hz: 30fps (640 × 360, 352 × 240) |
| Others |
Support rotate mode. Brightness, contrast, saturation, and sharpness are adjustable via web browser and client software |
| Network |
| Network Storage |
Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR |
| Alarm Trigger |
Motion Detection, VideoTampering, Network Disconnected, IP Address Conflicted, Illegal Login, HDD Full, HDD error |
| Protocols |
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,PPPoE,NTP,UPnP™,SMTP,SNMP,
IGMP,802.1X,QoS,IPv6, Bonjour
|
| General |
One-key Reset, Anti-Flicker, Heartbeat, Mirror, Password Protection, Privacy Mask, Watermark, IP Address Filter |
| Standard |
ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI |
| Interface |
| Communication Interface |
1 RJ45 10M/100M self-adaptive Ethernet port |
| Reset |
Built-in microSD/SDHC/SDXC slot, up to 128 GB |
| General |
Working Temperature
/Humidity |
-22 °F ~+140 °F(-30 °C ~ +60 °C ) Humidity 95% or less (non-condensing) |
| Power Supply |
DC 12V ± 25%,PoE(802.3af) |
| Power Consumption |
Max. 5.5W (Max. 7.5W with ICR on) |
| IR Range |
Up to 100ft (30m) |
| Weather Proof Ratings |
IP67 |
| Impact Protection |
IK10 |
| Dimensions |
Φ4.4″ × 3.2″ (Φ111 × 82.4 mm) |
| Weight |
1.1lbs (500g)
|
|
