The newest end‑to‑end video security platform from LTS. Entry to enterprise NVRs, and fixed, turret, dome, bullet, PTZ, fisheye and LPR cameras — every essential piece an installer needs to build a complete solution on one line of hardware.
Pro‑X is the newest end‑to‑end video security solution from LTS. Every essential piece is here, from recorders to cameras and beyond, so installers and integrators can design and quote a complete video security solution using exclusively Pro‑X hardware — no mixing part numbers across three product lines to hit a spec.
The range spans entry to enterprise recorders alongside fixed, vari-focal turret, dome and bullet cameras, plus PTZ, fisheye and LPR models. On top of the hardware sit the Pro‑X “X‑Factors” — a set of proprietary technologies (below) that separate Pro‑X from a standard IP camera range: faster investigation, active deterrence, longer PoE runs and around‑the‑clock colour.
Every Pro‑X product carries a lifetime warranty as standard — long‑term value and peace of mind, and a signal of how the range is engineered and tested.
The full Pro‑X series is NDAA‑compliant, meeting the sourcing standards required on government, critical infrastructure and many commercial tenders.
Pro‑X recorders speak ONVIF, so X‑Boost analytics can be layered onto a client’s existing camera estate — you don’t have to rip and replace to sell the upgrade.
LTS groups the Pro‑X advantage into three jobs a system has to do — investigate faster, deter actively, and see more — built from six named technologies across the range.
Tracks movement across cameras, pinpoints activity inside a defined zone, or finds a subject by traits like clothing colour or accessories — in seconds. 2.0 adds smart search for lost objects, target search across humans, vehicles and animals, and a target tracking map of a suspect’s path.
Combines a high‑decibel siren with red & blue flashing lights and custom triggered audio/video warnings. Paired with X‑Search, cameras now hunt threats in real time rather than just recording them — scored, tracked and escalated as they happen.
E‑Tracking gives digital zoom across a 180° panoramic camera paired with a 12MP sensor; Smart Auto Tracking drives the motorised housing on every PTZ model to follow a target automatically, handing off between cameras as it moves.
Radically extends power over standard Ethernet cabling — up to 980ft (300m) at 100Mbps, or up to 2,620ft (800m) at 10Mbps. One fewer excuse to run a separate power drop on a long perimeter or carpark run.
Lets a Pro‑X Ultra AI NVR add MD 2.0 human/vehicle detection, line‑crossing and face recognition to an existing IP camera install over ONVIF — a way to sell the AI upgrade on a job without swapping every camera on site.
A built‑in AI‑ISP chipset restores true colour, reduces noise and cuts motion blur in low light — usable colour footage around the clock, with sharper facial and object detail than standard Color 24/7.
From budget Lite turrets to 4K X‑Deterrence PTZs, every Pro‑X camera shares the same NVR ecosystem, mounting accessories and lifetime warranty. Highlights from the Q3 2026 range below — full specs and SKUs are in the current Pro‑X catalogue.
12MP and 8MP fixed cameras with Color 24/7, X‑Search 2.0, X‑PoE and human/vehicle detection as standard. The core Pro‑X camera line.
e.g. LXIP9C122WI‑28MDA · LXIP7C82WI‑28MDABuilt‑in AI‑ISP for enhanced colour, reduced noise and motion‑blur reduction after dark, at 4MP and 8MP.
e.g. LXIP9C82W‑28AISP · LXIP3C42W‑28AISPSiren, red & blue strobes and X‑Search threat hunting built into an 8MP turret or 180° panoramic body.
e.g. LXIP3C82NWI‑28SDL · LXIP3C8PWI‑SDL25x optical zoom PTZ with active deterrence, auto tracking and, on the panoramic‑plus‑PTZ model, linkage tracking that hands a moving target from a wide panoramic view straight into a 25x zoom.
e.g. LXPTZIP4C84WI‑X25IR · LXPTZIP4C8WI‑X25SDL25x–32x optical zoom, human/vehicle detection and auto tracking, up to 8MP resolution with True WDR 120dB.
e.g. LXPTZIP514W‑X32IR · LXPTZ518W‑25XRDual‑lens 4MP panoramic and 12MP fisheye options with Queue AI, heatmap and people counting for retail and reception areas.
e.g. LXIP7553W4‑SZ12 · LXIP75122F‑SEWarm light + IR dual illumination at 4MP–8MP for colour‑at‑night without a strobe, plus a vari‑focal Dual Light line at 2.7–13.5mm.
e.g. LXIP8582W‑28MDA · LXIP7783WE‑SDZ2.7–13.5mm motorised zoom across turret, dome and bullet bodies, 8MP, human/vehicle detection, True WDR 120dB.
e.g. LXIP3783W‑MDAZ · LXIP8783W‑SDZPurpose‑built license plate recognition bullet with 10–50mm varifocal lens and video metadata output.
LXIP9943LPR‑50RBudget entry point at 4MP–8MP, dual light option available, for jobs where every dollar of the BOQ counts.
e.g. LXIP1142W‑28MA · LXIP1182WE‑28MDA108dB max SPL PoE+ speaker with built‑in mic, for two‑way audio warnings tied into X‑Deterrence events.
LXA2WSP‑120DCard, PIN, Bluetooth and facial‑recognition readers, controllers and a touchscreen door station — up to 40 doors, no external software.
e.g. LXKCI202‑USB · LXK3411MF‑WIFIP
A 4MP doorbell that talks to the rest of the Pro‑X ecosystem: person & vehicle detection (MD 2.0), two‑way talk, and either a direct Wi‑Fi connection or a wired link straight into a Pro‑X NVR. Available solo or as a Video Doorbell + Chime kit.
Every Pro‑X NVR runs the same AI core — MD 2.0 human/vehicle detection as the baseline, X‑Search and facial recognition as you move up the range — so a spec written for a Core recorder still makes sense if the client upgrades later.
| Model | Channels | Recording | AI Features | Storage | Alarm I/O |
|---|---|---|---|---|---|
| LXN10864D | 64ch @ 1408Mbps32MP IPC access | Up to 8K/32MP | X‑Search 2.0, Facial Recognition, Human/Vehicle, VCA, RAID, hot‑swap N+M | 8 SATA to 20TB ea. | 16 / 8 |
| LXN108128D | 128ch @ 1408Mbps32MP IPC access | Up to 8K/32MP | X‑Search 2.0, Facial Recognition, Human/Vehicle, VCA, RAID, hot‑swap N+M | 8 SATA to 20TB ea. | 16 / 8 |
| Model | Channels | Built‑in PoE | AI Features | Storage | Alarm I/O |
|---|---|---|---|---|---|
| LXN9216D‑P16 | 16ch @ 384Mbps | 16CH | X‑Search 2.0, Facial Recognition, Human/Vehicle, VCA | 2 SATA to 16TB ea. | 4 / 2 |
| LXN9432D | 32ch @ 384Mbps | — | X‑Search 2.0, Facial Recognition, Human/Vehicle, VCA | 4 SATA to 16TB ea. | 16 / 6 |
| LXN9432D‑P24 | 32ch @ 384Mbps | 24CH | X‑Search 2.0, Facial Recognition, Human/Vehicle, VCA | 4 SATA to 16TB ea. | 16 / 6 |
| LXN9464D | 64ch @ 384Mbps | — | X‑Search 2.0, Facial Recognition, Human/Vehicle, VCA | 8 SATA to 16TB ea. | 16 / 8 |
| Model | Channels | Built‑in PoE | AI Features | Storage | Alarm I/O |
|---|---|---|---|---|---|
| LXN7104‑P4 | 4ch @ 80Mbps | 4CH | — (Lite) | 1 SATA to 10TB | — |
| LXN8208D‑P8 | 8ch @ 256Mbps | 8CH | Human/Vehicle, Smart Perimeter, Face Recognition | 2 SATA to 16TB ea. | 4 / 2 |
| LXN8216D‑P16 | 16ch @ 256Mbps | 16CH | Human/Vehicle, Smart Perimeter, Face Recognition | 2 SATA to 16TB ea. | 4 / 2 |
| LXN8432D‑P16 | 32ch @ 256Mbps | 16CH | Human/Vehicle, Smart Perimeter, Face Recognition | 4 SATA to 16TB ea. | 16 / 4 |
All Pro‑X NVRs decode H.265+/H.265/H.264, output up to 4K/8K over HDMI, and pair with Western Digital WD Purple and WD Purple Pro surveillance drives (1TB–26TB) for recording storage.
Pro‑X is a platform, not just a camera range — the app, switches, access control and VMS options are built to be quoted and deployed alongside the cameras and NVRs above.
Arm or disarm the whole property in one tap, filter notifications by event type instead of drowning in motion alerts, and review live view and event‑filtered playback side by side. Controls NVRs, IP cameras, access control and the door station from a single app. Upgrade path from the original Pro‑X App via QR code.
Gigabit PoE switches from 6‑port/4 PoE up to 28‑port/24 PoE, with VLAN, STP, flow control and PoE watchdog link aggregation — cloud‑managed alongside the rest of the estate.
Card, PIN, Bluetooth and facial‑recognition readers, a 4.3″ touchscreen door station with two‑way calling, and controllers that scale to 20 controllers / 40 doors — managed from a built‑in web server, no extra software licence.
Available as a standalone unit or a Video Doorbell + Chime kit — indoor wireless chime with multiple ringtones, doorbell records to on‑board microSD or straight to an NVR.
A VMS for up to 64 channels — live view, playback, backup and centralised device management from a single user account. The right fit for a single‑site retail, hospitality or light‑commercial job.
Unlimited, scalable VMS that unifies distributed sites into one system: adaptive streaming to save bandwidth, flexible storage across edge NVR, server and NAS, and server‑side AI — face recognition, LPR, vehicle make & model recognition, people counting and PPE detection.
Pro‑X sits on top of the same manufacturing, warranty and support operation behind every LTS product line — the numbers below describe the LTS network globally, not a single warehouse.
Every Pro‑X part number decodes the same way on a spec sheet or a quote line. Two examples from the current catalogue:
Straight from the LTS USA channel — product walkthroughs, feature demos and setup guides.
Plus 29 more feature walkthroughs on the LTS Pro‑X Features playlist, and step‑by‑step setup videos on LTS Academy – Pro‑X How‑to Guides.
Get the current catalogue, check NDAA documentation, or ask your LTS Australia rep for pricing on any Pro‑X model above.
