Ajax DomeCam Mini 8MP 4mm White PoE IP Dome Camera with AI Detection

Ajax DomeCam Mini 8MP 4mm White PoE IP Dome Camera

The Ajax DomeCam Mini (8MP/4mm) in white is a compact, wired IP dome camera built for integration into an Ajax security ecosystem while also functioning as a strong standalone surveillance device. With sharp 4K-class imaging, on-device AI object recognition, and a rugged weatherproof housing, it suits both residential entryways and commercial premises that need discreet, reliable video coverage tied to an intrusion alarm system.

Key Features

• 8MP resolution capturing video up to 3840 x 2160px at up to 20 frames per second for crisp, detailed footage.
• 4mm fixed lens delivering a focused 75° to 85° viewing angle, ideal for monitoring specific zones such as doorways or driveways.
• AI-powered object detection that distinguishes between humans, pets, and vehicles to cut down on false alerts and unnecessary recordings.
• Smart infrared illumination with automatic intensity adjustment for clear night-time footage without overexposing nearby objects.
• True WDR (hardware and software wide dynamic range) to balance bright and shadowed areas within the same frame.
• JetSparrow video protocol, Ajax's proprietary encrypted peer-to-peer streaming technology for fast, secure local and remote viewing.
• H.264 and H.265 compression supporting bitrates up to 100 Mbps for efficient storage without sacrificing image quality.
• Built-in microphone with G.711, G.726, and G.722 audio codec support for synced audio-video monitoring.
• Flexible powering via PoE (802.3at/af) or a 12V DC 1A supply, plus microSD (up to 256GB) or NVR storage options.
• IP65 and IK08-rated housing for dust, moisture, and impact resistance in both indoor and outdoor installations.

Built for Integrated Security Systems

This camera is designed to work seamlessly alongside Ajax intrusion and automation devices, allowing users to configure scenarios where a triggered detector automatically activates recording on the DomeCam Mini. This tight integration means that instead of just recording continuously, the camera can be set to arm and disarm alongside the wider Ajax security system, helping installers deliver a genuinely unified security and video verification solution for homes, retail premises, offices, and warehouses.

What's in the Box

• Ajax DomeCam Mini (8MP/4mm) camera unit - White
• Mounting bracket and installation template
• Mounting screws and hexagon key
• Cable with connectors
• Quick start guide

Frequently Asked Questions

Does this camera need an Ajax alarm system to work?
No. The DomeCam Mini functions as a standalone IP camera, but it offers extra scenario-based automation and event-triggered recording when paired with an Ajax hub and detectors.

Is a memory card included?
No, storage media is sold separately. The camera supports a microSD card up to 256GB (Class V30 or faster) or recording to a compatible NVR with a hard drive up to 16TB.

Can this camera be powered without PoE?
Yes. It can be powered via PoE (802.3at/af) or a standard 12V DC 1A power supply, giving installers flexibility depending on existing cabling.
