LTS Platinum 16ch NVR Kit with 8x 8MP AI Colour247 Cameras & 6TB HDD

LTS Platinum 16-Channel NVR Kit with 8x 8MP AI Colour247 Turret Cameras (LTSC168)

The LTSC168 is a complete 16-channel Platinum surveillance kit built for businesses and properties that need sharp, full-colour footage around the clock. It pairs an AI-enabled 16-channel PoE NVR with eight 8MP hybrid-light turret cameras, giving you wide coverage, smart analytics, and a pre-installed security-grade hard drive so the whole system is ready to record straight out of the box.

Key Features

• 8MP AI Colour247 Imaging: Each camera uses an F1.0 super-aperture lens and an advanced AI image signal processor to keep footage in full colour day and night, without relying purely on infrared.
• Smart Hybrid Lighting: Built-in IR and white light work together across multiple lighting modes to maintain clear colour detail in low-light and night scenes.
• AI Human and Vehicle Classification: On-camera and on-NVR analytics filter out irrelevant motion, cutting down false alerts from wind, animals, or shadows.
• Built-In Audio and Active Deterrence: Cameras include a dual-microphone array plus a strobe light and audio alarm that can trigger automatically to warn off intruders.
• Weatherproof, Rugged Housing: IP67 water and dust resistance combined with NEMA4X-rated anti-corrosion housing suits outdoor and harsh-environment installs.
• 16-Channel PoE NVR with Facial Recognition: The included Platinum D-Series NVR supports up to 160 Mbps incoming bandwidth, H.265+/H.264+ compression, and a dedicated facial recognition channel with face image library search.
• 4K Local Output: View live and recorded footage in sharp detail via independent HDMI and VGA outputs.
• 6TB Security-Grade Hard Drive Included: A surveillance-rated 6TB HDD comes pre-fitted, purpose-built for continuous NVR recording workloads.

Built for Reliable, Round-the-Clock Monitoring

This kit suits retail stores, warehouses, offices, and residential properties that need dependable colour footage at any hour along with smart alerting. The combination of AI-based human and vehicle detection with facial recognition on the NVR makes it easier to review incidents quickly, while the plug-and-play PoE design keeps installation straightforward for eight cameras across a single system.

What's in the Box

• 8 x LTS Platinum 8MP AI ISP Hybrid Colour247 Turret IP Cameras (2.8mm lens)
• 1 x LTS Platinum 16-Channel D-Series PoE NVR with 1-Channel Facial Recognition
• 1 x 6TB Security-Grade Hard Disk Drive (pre-installed)

Frequently Asked Questions

Do the cameras need a separate power supply?
No. The NVR provides Power over Ethernet (PoE) to all eight cameras through its built-in PoE ports, so only a single network cable is needed per camera.

Can I add more cameras later?
Yes. The NVR supports up to 16 IP camera channels, so an additional 8 compatible cameras can be added beyond the 8 included in this kit.

Is the 6TB hard drive enough for continuous recording?
Storage duration depends on camera resolution, frame rate, and compression settings, but the included 6TB security-grade drive is sized to suit typical continuous recording setups for an 8-camera 8MP system. Additional storage can be added via the second SATA bay.
