LTS PRO-X 16-Channel 6TB NVR Kit with 8x 12MP Dual-Light Turret Cameras

LTS PRO-X 16-Channel 6TB NVR Kit with 8x 12MP Dual-Light Turret Cameras

This complete PRO-X surveillance kit pairs a 16-channel NDAA-compliant NVR with eight ultra-high-resolution 12MP turret cameras, giving businesses and larger residential properties a ready-to-deploy, professional-grade recording system. Built around LTS's Pro-X Series, the kit combines high-resolution imaging, AI-based analytics, and generous onboard storage in a single package designed for straightforward installation and long-term reliability.

Key Features

• 16-channel PoE NVR with 16 independent PoE ports, so cameras can be powered and connected without a separate switch.
• Supports resolutions up to 16MP per channel, with 4K HDMI output and VGA output up to 1080p for flexible monitor setups.
• 6TB security-grade hard drive included, installed in a chassis with dual SATA bays supporting up to 16TB per drive for future expansion.
• Eight 12MP dual-light turret cameras capturing detailed 4512 x 2512 resolution footage at up to 15fps via a 1/2.5-inch CMOS sensor.
• Hybrid IR and warm-light illumination on each camera, extending clear night-time visibility to roughly 30 metres (98ft).
• Built-in AI analytics including human and vehicle motion detection (MD 2.0), face recognition, and line-crossing detection on supported channels.
• Smart H.265/H.264 encoding across both the NVR and cameras to reduce bandwidth and storage consumption without sacrificing image quality.
• NDAA-compliant design, making the kit suitable for government, education, and other regulated procurement environments.
• Remote access via the Pro-X mobile app, allowing live viewing, playback, and system management from anywhere.

Ideal Applications

This kit suits medium to large sites that need dense, high-resolution camera coverage, such as retail stores, warehouses, car parks, schools, and multi-entry commercial buildings. The combination of a 16-channel NVR and eight cameras leaves room to expand coverage later, while the dual-light illumination and AI motion detection help reduce false alarms and improve footage usefulness for identifying people and vehicles after an incident.

What's in the Box

• 1 x LTS PRO-X 16-Channel NVR (LXN8216D-P16), NDAA compliant
• 1 x 6TB Security-Grade Hard Drive (pre-installed)
• 8 x LTS PRO-X 12MP Dual-Light Turret IP Cameras (LXIP3C122WI-28MDA), NDAA compliant

Frequently Asked Questions

Can I add more cameras later?
Yes. The NVR supports up to 16 channels, so up to eight additional PoE cameras can be added within the recorder's PoE and bandwidth limits.

Is a monitor included?
No, a monitor is not included. The NVR outputs via HDMI (up to 4K) or VGA (up to 1080p), so any compatible display can be connected separately.

Does this kit support the X-Search feature mentioned for these cameras?
No. X-Search functionality is only available when the cameras are paired with an LTS 9 Series Ultra Intelligent NVR, not the included Pro-X 16-channel model.
