LTS PRO-X 8-Channel 12MP NVR Kit with 2TB HDD & 4 Turret Cameras

LTS PRO-X 8-Channel 2TB NVR Kit with 4 x 12MP Dual-Light Turret Cameras

The LTS PRO-X 8CH 2TB + 4x 12MP Kit (LTSPX412) is a complete, NDAA-compliant IP surveillance system built for installers and end users who need ultra-high-resolution coverage straight out of the box. The kit pairs the LTS Pro-X LXN8208D-P8 8-channel PoE NVR, pre-loaded with a 2TB security-grade hard drive, with four Pro-X 12MP dual-light turret IP cameras, giving you sharp 5K-class imaging, built-in AI analytics, and simple plug-and-play PoE installation.

Key Features

• 8-Channel PoE NVR: The LXN8208D-P8 includes 8 built-in PoE ports, so cameras receive power and data over a single cable with no separate injectors required.
• Supports up to 16MP recording: The NVR handles resolutions up to 16MP, with a total incoming bandwidth of 256Mbps (180Mbps with MD 2.0 enabled).
• 4K HDMI output: Video can be displayed at up to 4K (3840 x 2160) via HDMI, or 1080p via VGA, for flexible monitoring setups.
• Expandable storage: Includes a pre-installed 2TB hard drive, with room to grow since the NVR accepts two SATA drives at up to 16TB each for up to 32TB total.
• Built-in AI detection: MD 2.0 technology on the NVR delivers human and vehicle motion detection to cut down on false alarms.
• 12MP Pro-X turret cameras: Each camera in the kit outputs up to 12MP (4512 x 2512) resolution for exceptional image clarity and cropping detail.
• Dual/hybrid illumination: The cameras use built-in IR and warm light LEDs with a matrix distance of up to 98.43 ft for clear vision day and night, in colour or infrared mode.
• Weatherproof and NDAA compliant: Rated IP67 for outdoor use, with metal-and-plastic housing and full NDAA compliance for government and enterprise projects.
• Built-in microphone: Each turret camera records audio alongside video for more complete evidence capture.

Built for Serious Property Protection

This kit suits homeowners, retail stores, warehouses, and commercial sites that need dependable, high-resolution coverage across multiple points without juggling separate power supplies or complicated wiring. The combination of a PoE NVR and four 12MP cameras makes it straightforward for installers to deploy a professional-grade system quickly, while the AI-based human and vehicle detection helps reduce nuisance alerts from pets, weather, or passing traffic.

What's in the Box

• 1 x LTS Pro-X LXN8208D-P8 8-Channel PoE NVR (NDAA Compliant)
• 1 x 2TB Security-Grade Hard Drive (pre-installed)
• 4 x LTS Pro-X LXIP3C122WI-28MDA 12MP Dual-Light Turret IP Cameras (NDAA Compliant)

Frequently Asked Questions

Does this kit support X-Search video playback?
X-Search is a feature reserved for LTS's 9 Series Ultra intelligent NVRs, so it is not available on the 8 Series LXN8208D-P8 included in this kit, even though the cameras support it with a compatible recorder.

Can I add more cameras later?
Yes. The NVR has 8 PoE channels in total, so you can connect up to four additional compatible IP cameras beyond the four included in this kit.

Can I upgrade the storage capacity?
Yes, each of the two SATA bays supports drives up to 16TB, allowing for up to 32TB of total storage if you need more than the included 2TB.
