Ajax TurretCam HL 5MP White 2.8mm Hybrid Illumination IP Camera

Ajax TurretCam HL 5MP White 2.8mm Hybrid Illumination IP Camera

The Ajax TurretCam HL is a wired AI-powered turret IP camera that pairs a 5 MP sensor with a 2.8 mm wide-angle lens for full coverage of entrances, yards, and indoor spaces. Its standout feature is hybrid illumination, which automatically blends infrared and white light so footage stays clear and in full colour even in total darkness, while the sudden white light burst doubles as a visible deterrent to intruders.

Key Features

• 5 MP resolution with a 2.8 mm lens delivering a wide 100–110° field of view, ideal for entrances and open areas
• Hybrid illumination that automatically switches between infrared and white LED light depending on scene conditions and motion detection
• TrueWDR for balanced exposure in high-contrast lighting, such as bright backgrounds or strong shadows
• AI-powered detection that distinguishes between people, vehicles, and animals to help reduce false alerts
• Built-in microphone for on-site audio capture alongside video
• Flexible power options via PoE or 12 V DC, simplifying cabling on new or existing installations
• IP65 and IK08 rated housing, built to resist dust, rain, and physical impact for reliable outdoor or indoor use
• Local microSD storage of up to 256 GB (Class V30 or faster), plus support for NVR and third-party VMS via ONVIF Profile T
• JetSparrow protocol, Ajax's encrypted peer-to-peer video technology, for fast and secure streaming

Built for Everyday Security Applications

This camera suits homeowners and businesses that want dependable round-the-clock monitoring without the cost of dedicated lighting. It works well at front doors, driveways, retail entrances, and warehouse perimeters, and integrates directly with the wider Ajax ecosystem so detectors can trigger recording automatically for a coordinated security response.

What's in the Box

• Ajax TurretCam HL 5MP 2.8mm camera (white)
• Mounting bracket and screws
• Hex key for enclosure access
• Quick start guide

Frequently Asked Questions

Does this camera need a separate Ajax hub to operate?
No, TurretCam HL connects via Ethernet cable and can be powered by PoE or a 12 V supply, though it can also be linked into a wider Ajax security system for automated scenarios.

How far does the hybrid illumination reach?
Both the infrared and white light illumination are effective up to roughly 50 metres, depending on installation height and environmental conditions.

Can footage be stored without an NVR?
Yes, the camera accepts a microSD card of up to 256 GB for local recording, in addition to NVR and VMS integration options.
