HDMI Over Coax

SMPTE Standard

425M Level A & B,424M,292M,259M-C

SDI Transmission Rates

2.970 Gbit/s and 2.970/1.001 Gbit/s

Frequency Bandwidth

225MHz/link (HDMI 1.3)

In/Output Support

Resolution

480I,576I,720p@50/59.94,60

1080I@50/59.94/60

1080P@23.98/24/25/29.97/30/50/59.94/60

1080PsF@23.98/24/25/29.97/30

Input Port

1 x BNC (SDI/HD-SDI/3G-SDI)

Output Port

1 x HDMI,

Power Supply

5V DC/1AÊàñDC12V/500mA

ESD Protection Human body model

±8kV (air-gap discharge)

±4kV (contact discharge)

SDI Cable Distance

3G up to100M(BELDEN1694A)

HD up to200M(BELDEN1694A)

SD up to300M(BELDEN1694A)

Dimension (mm)

80mm x41mmx25 mm

Weight (g)

150g
