Akuvox E12S Door Station & C313 Black Indoor Monitor IP Intercom Kit

Akuvox E12S & C313 Black IP Video Intercom Kit

This Akuvox intercom kit pairs the compact E12S SIP video door station with the 7-inch C313 touchscreen indoor monitor in a black finish, giving homes, townhouses and small offices a complete two-way video entry system. Built on an IP network foundation, the kit lets residents see, hear and speak with visitors, then release the door or gate from either the indoor monitor or a smartphone once configured with the SmartPlus app.

Key Features

• 2MP wide-angle camera on the E12S door station with a 123° horizontal field of view for clear visitor identification
• H.264/H.265 video support with resolutions up to 1080p for sharp, low-bandwidth-friendly streaming
• 7-inch capacitive touchscreen on the C313 indoor monitor with an 800 x 480 display and energy-saving standby mode
• Flexible power options - both units accept PoE or 12V DC power, simplifying cabling and installation
• RFID, NFC and Bluetooth credentials supported at the door station for keyless entry alongside traditional call buttons
• IP65-rated door station housing built to withstand outdoor weather exposure
• SIP v2 and ONVIF compliance for straightforward integration with existing intercom or access infrastructure
• Built-in microphone and speaker on the indoor monitor for handsfree two-way conversations
• SmartPlus mobile app compatibility, allowing remote visitor viewing, talk and door release from a smartphone

Typical Applications

This kit suits single-dwelling homes, townhouses, small offices and low-rise apartment entries where a simple, self-contained SIP video intercom is needed. It is well suited to installers replacing a dated analogue doorbell or wired intercom with an IP-based solution that still supports smartphone notifications and remote access, without needing a full multi-tenant server platform.

What's in the Box

• 1 x Akuvox E12S IP Video Door Station
• 1 x Akuvox C313 7-inch Indoor Monitor (Black)
• Mounting hardware and quick-start documentation
• Free SmartPlus app activation accounts (subject to Akuvox terms)

Frequently Asked Questions

Does this kit include a PoE switch?
No. A PoE switch is required to power the door station and monitor but is sold separately.

Can I use this kit without an internet connection?
The intercom will operate locally over the LAN for door station-to-monitor calling, but remote smartphone access via the SmartPlus app requires an internet connection.

Is the door station suitable for outdoor installation?
Yes, the E12S door station carries an IP65 weather-resistance rating, making it appropriate for exposed outdoor entry points.
