Ajax NVR HAC 16-Channel White Network Video Recorder with HDMI Output

Ajax NVR HAC 16-Channel White Network Video Recorder with HDMI Output

The Ajax NVR HAC (16-ch) is a network video recorder built for sites that need dependable local recording alongside remote monitoring. Housed in a compact white casing, this recorder connects directly to a monitor or TV via HDMI, giving installers and end users an instant, on-site view of every camera without needing a laptop or mobile app. It integrates smoothly with the Ajax security ecosystem while also supporting third-party ONVIF and RTSP IP cameras, making it a flexible core for both new and existing camera installations.

Key Features

• 16-channel support for managing footage from up to 16 IP cameras on one device.
• Built-in HDMI output for direct, app-free viewing of live and recorded footage on a connected display.
• Onboard video management software (VMS) that can be navigated locally with a mouse and keyboard.
• Up to 4K resolution recording at 25/30 FPS on supported channels, with ONVIF Profile S/T and RTSP compatibility.
• Large local storage capacity via a single 3.5-inch SATA hard drive, supporting drives up to 16TB (HDD not included).
• Dual USB Type-A ports for connecting a mouse, keyboard, or USB flash drive.
• Smart motion detection with configurable detection zones to reduce irrelevant footage and conserve storage.
• Ajax ecosystem integration, allowing detectors to automatically trigger and highlight camera feeds during an alarm event.
• Encrypted video streaming using TLS/mTLS, plus passcode, biometric, and two-factor account protection.

Ideal Applications

This recorder suits homes, offices, retail stores, and small-to-medium commercial sites that want a single screen showing every camera in real time, particularly where guard posts, reception desks, or control rooms need an always-on local display. Because it works even without an active internet connection once configured, it's also a solid choice for sites with unreliable connectivity that still want continuous local recording, while remote users can still check in via Ajax apps when internet is available.

What's in the Box

• Ajax NVR HAC (16-ch) unit in white
• SmartBracket mounting panel
• Mounting screws and accessories
• Power supply cable
• Quick start guide

Frequently Asked Questions

Does this NVR come with a hard drive?
No. The unit supports a single 3.5-inch SATA HDD or SSD up to 16TB, but the drive must be purchased separately.

Can I use non-Ajax cameras with this recorder?
Yes. In addition to Ajax video devices, the NVR HAC supports third-party IP cameras that use ONVIF and RTSP protocols.

Do I need the internet to view footage locally?
No. Once set up, the built-in VMS lets you view live and recorded footage through the HDMI-connected display without an active internet connection, though initial setup does require internet access.
