Ajax Hub 2 (4G) White Wireless Alarm Control Panel with Photo Verification

Ajax Hub 2 (4G) White Wireless Alarm Control Panel

The Ajax Hub 2 (4G) is the central brain of an Ajax wireless security system, coordinating every connected sensor, camera and accessory from one compact white unit. Built around Ajax's encrypted Jeweller radio protocol, it links to the Ajax Cloud through three independent communication paths, giving installers and end users a highly resilient alarm platform for homes, offices and commercial sites across Australia.

Key Features

• Triple-redundant connectivity: Combines Ethernet with two SIM card slots supporting 2G/3G/4G (LTE) networks, so the hub automatically switches carriers or channels if one connection drops.
• Photo verification support: Works with Ajax MotionCam and MotionCam Outdoor detectors over the Wings protocol, sending event photos to confirm real intrusions before dispatching a response.
• Large device capacity: Supports up to 100 connected Ajax devices, 50 system users, 50 protected rooms and 25 linked video cameras or DVRs.
• Flexible automation: Runs up to 32 custom scenarios and organises devices into 9 separate security groups for multi-zone or multi-tenant sites.
• Secure by design: Encrypted, two-way Jeweller communication with a dynamic key protects against jamming, interception and tampering, while the hub runs on Ajax's own OS Malevich with built-in anti-malware protection.
• Reliable backup power: An internal Li-Ion battery keeps the system running for many hours during a mains power outage, with instant notification sent if power is lost.
• Constant device health checks: Connected sensors are polled every few seconds so faults, low batteries or tampering are detected quickly.
• Clean, discreet housing: A white plastic enclosure with concealed connectors and buttons suits residential and commercial interiors alike.
• Full app control: Arm, disarm, monitor and manage the entire system remotely through the Ajax mobile and PRO apps.

Ideal Applications

The Hub 2 (4G) suits homes, retail premises, offices and multi-room facilities that need a dependable alarm system without relying on a single internet connection. Its dual-SIM cellular backup makes it particularly useful for sites with unreliable fixed-line internet, remote locations, or businesses that require connection to a central monitoring station and want confirmed, photo-verified alarm events rather than false-alarm callouts.

What's in the Box

• Ajax Hub 2 (4G) control panel, White
• Mounting bracket and installation hardware
• Power supply cable
• Backup battery (installed)
• Quick start guide

Frequently Asked Questions

Does the Hub 2 (4G) need a SIM card to work? No, it can run on Ethernet alone, but installing one or two SIM cards adds a cellular backup channel for extra reliability.

Can it use MotionCam photo verification? Yes, it is fully compatible with Ajax MotionCam and MotionCam Outdoor detectors, receiving event photos over the encrypted Wings protocol.

How many devices can be connected? The Hub 2 (4G) supports up to 100 Ajax devices, 50 users and 25 cameras within a single system.
