Ajax KeyPad Plus White Wireless Touch Keypad with Contactless Card Reader

Ajax KeyPad Plus White - Wireless Touch Keypad with Contactless Access

The Ajax KeyPad Plus is a wireless touch-panel keypad designed to arm, disarm, and manage an Ajax security system with speed and style. Finished in white to suit modern interiors, it combines discreet touch-button controls with a built-in reader for encrypted Ajax Pass cards and Ajax Tag key fobs, giving users the flexibility to authenticate with a code, a card, or a fob. The keypad communicates with the hub over Ajax's proprietary Jeweller radio protocol, delivering long range and dependable two-way status reporting for homes, offices, and commercial sites.

Key Features

• Contactless authentication: Built-in reader supports Ajax Pass cards and Ajax Tag key fobs using DESFire encrypted chips for fast, secure identification.
• Long wireless range: Connects to compatible Ajax hubs via the Jeweller protocol with a line-of-sight range of up to 1,700 metres.
• Extended battery life: Runs on pre-installed AA batteries for up to 3.5 years with the card/fob reader active, or up to 4.5 years with it disabled.
• Duress code support: Entering a hidden duress code triggers a silent alarm to alert the monitoring station without alerting an intruder.
• Anti-tamper protection: Sends instant alerts if the keypad is removed from its mounting bracket or forcibly detached from a wall.
• Passcode guessing protection: Automatically locks out after repeated incorrect code entries, with the lockout period configurable in the Ajax app.
• LED status indication: Backlit touch buttons and status LEDs show the current arm/disarm state at a glance, even without opening the app.
• Scenario and automation trigger: Arming or disarming via the keypad can automatically switch off lights, appliances, or close roller shutters through Ajax automation scenarios.
• Simple setup: Pairs with a hub in seconds via QR code scan, with no enclosure disassembly required.

Ideal For Homes, Offices, and Multi-User Sites

KeyPad Plus suits any Ajax-protected property where multiple people need convenient, individually tracked access. Assign personal codes, cards, or fobs to family members, staff, or cleaning contractors, then monitor exactly who armed or disarmed the system and when. Because access rights can be adjusted or revoked instantly through the Ajax app, it is well suited to offices, retail premises, and rental properties where user turnover is common.

What's in the Box

• Ajax KeyPad Plus keypad unit (White)
• Mounting bracket / SmartBracket
• Pre-installed AA batteries
• Mounting screws and fixings
• Quick start guide

Frequently Asked Questions

Which Ajax hubs is KeyPad Plus compatible with?
It works with Hub Plus, Hub 2, and Hub 2 Plus running compatible firmware; it is not supported on the Hub (2G) or via bridge integration modules.

Can KeyPad Plus be used outdoors?
No, it is designed for indoor installation only.

How many cards or fobs can be registered?
Depending on the connected hub model, an Ajax system can support up to 200 Pass cards or Tag key fobs in total.
