LTS 7" IP PoE Wi-Fi Video Intercom Indoor Monitor, Black

LTS LTH-D301GY-WIFI 7" IP-PoE Video Intercom Indoor Monitor

The LTH-D301GY-WIFI is an IP-based indoor intercom monitor built for apartments, offices and residential entries that need reliable video calling and door release control. A 7-inch capacitive touchscreen running an embedded Linux interface gives residents an easy way to view visitors, talk hands-free and release locks from inside the building, while both PoE and Wi-Fi connectivity keep installation flexible for retrofits or new network cabling.

Key Features

• 7-inch touchscreen display with a sharp 1024 x 600 resolution for clear visitor video and menu navigation
• Built-in microphone and speaker for full hands-free two-way audio communication with linked door stations
• Dual connectivity options - standard 802.3af PoE (6W) or 12V DC power, plus 10/100Mbps Ethernet and 802.11b/g/n Wi-Fi
• Local storage on microSD for captured snapshots and messages, supporting cards up to 32GB
• Remote monitoring and unlocking through compatible mobile apps or NVMS V3 client software
• Live viewing of linked door stations and IP cameras directly from the monitor screen
• Multi-unit friendly design, supporting up to six indoor monitors per apartment configuration
• Wide operating temperature range from -10°C to 55°C, suited to most indoor Australian climates
• Slim wall-mount profile with a Black/Silver trim that suits residential and commercial interiors

Ideal Applications

This intercom monitor is well suited to residential entry systems, apartment buildings, small offices and gated properties where a networked, PoE-powered indoor station is preferred over analog wiring. Because it can run over Ethernet or Wi-Fi, it works equally well in new-build installs with structured cabling or in retrofit projects where running new cable to every unit is impractical. Paired with a compatible LTS IP door station, it forms a complete video entry solution with app-based remote answering for tenants who are away from their unit.

What's in the Box

• LTH-D301GY-WIFI 7" Indoor Intercom Monitor
• Mounting bracket and wall-fixing screws
• Power/network terminal connectors
• Quick Start Guide

Frequently Asked Questions

Does this monitor need a PoE switch or injector?
No, it can be powered either through a standard 802.3af PoE source or via a separate 12V DC power supply, so a PoE switch is optional rather than mandatory.

Can I access the intercom remotely from my phone?
Yes, the monitor supports door station app access, allowing remote viewing and unlocking when connected to a compatible network or Wi-Fi.

How many of these monitors can be installed per apartment?
Up to six indoor monitors can be linked within a single apartment or unit configuration for multi-room answering.

Additional Resources

• Quick Start Guide
